ab 10,97 €
| ab 1 Stk. | 11,35 € |
|---|---|
| ab 3 Stk. | 11,24 € |
| ab 10 Stk. | 10,97 € |
2 vorrätig
| Input voltage | 100 – 240 VAC |
| Input frequency | 50/60 Hz |
| Input current | 0.8 A |
| Input connector | EU (Type C) |
| Output voltage | 12 VDC |
| Output current | 2.0 A |
| Output connector | 4pin, 3 mm pitch |
| Weight | 115 g |
| Input voltage absolute maximum | 90 – 264 VAC |
| Input frequency absolute maximum | 47 – 63 Hz |
| Inrush currect | 60 A |
| Output voltage absolute maximum | ± 0.6 VDC |
| Short circuit protection | |
| HIPOT (dielectric withstand test) | Primary to Secondary: 4000 VDC |
| MTBF | 30000 h |
| PSU efficiency standard | DoE Level VI |
Zum Download / Öffnen auf das PDF-Bild klicken
