ab 20,97 €
| ab 1 Stk. | 21,70 € |
|---|---|
| ab 3 Stk. | 21,49 € |
| ab 10 Stk. | 20,97 € |
Vorrätig
| Input voltage | 100 – 240 VAC |
| Input frequency | 50 / 60 Hz |
| Input current | 1.5 A |
| Input connector | EU (Type C) |
| Output voltage | 48 VDC |
| Output current | 1.3 A |
| Output connector | 4-pin, 3 mm pitch |
| Weight | 330 g |
| Input voltage range | 90 – 264 VAC |
| Input frequency range | 47 – 63 Hz |
| Maximum input inrush current | 50 A |
| Output voltage maximum deviation | 45.6 – 50.4 VDC > |
| Short circuit protection | |
| HIPOT (dielectric withstand test) | Primary to Secondary: 4000 VDC |
| MTBF | 50000 h |
Zum Download / Öffnen auf das PDF-Bild klicken
